Specifications
General
Built: 1991 – major refit in 2009
Class: BV 1 ✠ HULL •MACH (Dynapsos AM / AT) Special service / Support vessel
Dimensions
Length over all: 45.6m
Beam over all: 11.5m
Maximum draught: 2.3 / 3.0m
Deck space: 300 m²
Machinery/Propulsion
MAIN ENGINES: 2x Mitsubishi V16 2000hp
Propulsion: 2x Schottel azimuth
Speed: 15 kts max
Operation range: 3000Nm @ 12,5 kts
Aux Gens: Mitsubishi 2 x 230 KW
Deck Machinery
CRANE 1 Type Hydro Armor 40 TON/M (2300 KG in 11,8 M)
CRANE 2 Viscovo 14 TON/M (800 KG in 10,5 M)
A-FRAME 17 TON SWL
Double drum bopp Winch -12,8 TON (first layer)
ROV
Cougar XT34
USBL SYSTEM GAPS IXSEA
SONAR KLEIN 3000 / 800 M winch
Additional information
Accomodation suitable for 18 persons
2x ZODIAC Rhibs
